Panasonic 100 μF Surface Mount Polymer Capacitor, 25 V | EEHZC1E101XP
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 15 pcs
Mfr. Part No: EEHZC1E101XP
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Panasonic |
| Product Type | Polymer Capacitor |
| Technology | Hybrid |
| Capacitance | 100μF |
| Voltage | 25 V |
| Mount Type | Surface Mount |
| Polarity | Polar |
| Lead Pitch | 1.8mm |
| Tolerance | ±20 % |
| Maximum Operating Temperature | 125°C |
| Dimensions | 6.3 (Dia) x 7.7 mm |
| Series | ZC |
| Height | 7.7mm |
| Length | 7.7mm |
| Electrolyte Type | Hybrid |
| Minimum Operating Temperature | -55°C |
| Ripple Current | 1400mA |
| Leakage Current | 25μA |
| Diameter | 6.3 mm |
| Lifetime | 4000 h, 1000 h |
| Automotive Standard | AEC-Q200 |
| Dissipation Factor | 14% |
Product Details
Panasonic Series ZC Polymer Capacitor, 100μF Capacitance, 25V DC Voltage – EEHZC1E101XP
This polymer capacitor is designed for reliable performance in demanding applications. With a capacitance of 100 μF and an operating voltage of 25V DC, it is optimised for surface mount technology. Its Compact dimensions measure 6.3mm in diameter and 7.7mm in height, making it suitable for a variety of electronic applications.
Features & Benefits
• Low equivalent series resistance ensures efficient power management
• Tolerates extreme temperatures from -55 °C to +125 °C
• High lifetime rating of 1000 hours at maximum voltage
• Leakage current limited to 25 μA for enhanced reliability
• Polarised design allows for versatile circuit integration
• Hybrid technology combines the benefits of electrolytic and ceramic capacitors
Applications
• Used in automotive requiring AEC-Q200 compliance
• Suitable for high-frequency power supply circuits
• Applied in consumer electronics for improved performance
• Utilised in industrial automation systems for stability
• Common in portable devices where space is limited
What is the significance of the low equivalent series resistance in this component?
The low equivalent series resistance (ESR) allows for reduced power losses during operation, leading to higher efficiency and improved overall performance in various electronic circuits.
How does this component perform under varying temperature conditions?
It is designed to operate effectively in a wide temperature range, from -55 °C to +125 °C, ensuring consistent performance in both extreme heat and cold environments.
What advantages does the hybrid technology offer for this capacitor?
Hybrid technology combines the benefits of both electrolytic and ceramic capacitors, providing enhanced stability and performance in power management applications.
