Panasonic 100 μF Surface Mount Polymer Capacitor, 35 V | EEHZK1V101XP
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 9 pcs
Mfr. Part No: EEHZK1V101XP
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Panasonic |
| Product Type | Polymer Capacitor |
| Technology | Hybrid |
| Capacitance | 100μF |
| Voltage | 35 V |
| Mount Type | Surface Mount |
| Polarity | Polar |
| Lead Pitch | 1.8mm |
| Tolerance | ±20 % |
| Maximum Operating Temperature | 125°C |
| Dimensions | 6.3 (Dia) x 7.7 mm |
| Series | ZK |
| Length | 7.7mm |
| Height | 7.7mm |
| Depth | 7.7mm |
| Electrolyte Type | Hybrid |
| Lifetime | 4000 h |
| Automotive Standard | AEC-Q200 |
| Diameter | 6.3 mm |
| Leakage Current | 35μA |
| Ripple Current | 1700mA |
| Minimum Operating Temperature | -55°C |
| Dissipation Factor | 12% |
Product Details
Panasonic Series ZK Polymer Capacitor, 100μF Capacitance, 35V DC Voltage – EEHZK1V101XP
This polymer capacitor is designed for efficiency in various applications within the electronics industry. With a capacitance of 100 μF and a voltage rating of 35V DC, it is suitable for both automotive and general applications. This surface mount component measures 6.3mm in diameter and has a height and depth of 7.7mm. The hybrid capacitor technology employed ensures optimal performance in demanding environments.
Features & Benefits
• Utilises hybrid capacitor technology for enhanced reliability
• Low equivalent series resistance of 35 mΩ improves efficiency
• Capable of functioning within a temperature range of -55 °C to +125 °C
• Tolerance of ±20 % ensures consistent performance
• Designed with an aluminium dielectric for superior thermal stability
• Offers a lifespan of up to 4000 hours for long-term use
Applications
• Used for power supply smoothing in automotive systems
• Suitable for filtering in electronic circuits
• Employed in energy storage solutions for various devices
• Ideal for high-temperature environments in the automotive industry
What advantages does the low ESR characteristic provide in applications?
The low equivalent series resistance reduces energy loss during operation, enhancing overall system efficiency and performance, particularly in high-frequency applications.
How does the temperature rating affect the functionality of the component?
The wide temperature rating enables reliable operation across various environmental conditions, making it suitable for both extreme cold and high-temperature usage in automotive applications.
What considerations should be kept in mind regarding the lifetime of this capacitor?
The stated lifetime of 4000 hours is contingent on the operating conditions; maintaining voltage within specified limits and ensuring proper thermal management can extend the component’s functional longevity.
What are the implications of the ±20 % tolerance on circuit design?
The ±20 % tolerance allows for flexibility in circuit design, as it provides a range within which the capacitance can vary while still achieving desirable performance in most applications.
