Panasonic 100 μF Surface Mount Polymer Capacitor, 50 V | EEHZA1H101P
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 12 pcs
Mfr. Part No: EEHZA1H101P
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Panasonic |
| Technology | Hybrid |
| Product Type | Polymer Capacitor |
| Capacitance | 100μF |
| Voltage | 50 V |
| Mount Type | Surface Mount |
| Polarity | Polar |
| Lead Pitch | 4.6mm |
| Tolerance | ±20 % |
| Maximum Operating Temperature | 105°C |
| Dimensions | 10 x 10.2 mm |
| Length | 10.2mm |
| Series | ZA |
| Height | 12mm |
| Electrolyte Type | Hybrid |
| Automotive Standard | AEC-Q200 |
| Minimum Operating Temperature | -55°C |
| Lifetime | 10000 h |
| Diameter | 10 mm |
| Ripple Current | 2000mA |
| Leakage Current | 50μA |
| Dissipation Factor | 10% |
Product Details
Panasonic Series ZA Polymer Capacitor, 100μF Capacitance, 50V DC Voltage – EEHZA1H101P
This polymer capacitor is an essential component designed for surface mount applications. With a capacitance of 100 μF and a voltage rating of 50V DC, it efficiently operates in high-temperature environments. Measuring 10 x 10.2mm with a diameter of 10mm, its hybrid technology ensures optimal performance for a variety of electronic circuits.
Features & Benefits
• High reliability with a lifetime of 10,000 hours
• Low equivalent series resistance of 28 mΩ enhances efficiency
• Tolerance of ±20 % ensures consistent performance
• Operates effectively in temperatures ranging from -55 °C to +105 °C
• Leakage current capped at 50 μA for minimal energy loss
• Polarised design optimises functionality in automotive applications
Applications
• Used in automotive electronic control units
• Ideal for power supply filtering in industrial automation
• Suitable for energy storage in consumer electronics
• Utilised in power management circuits for renewable energy systems
What is the significance of the low equivalent series resistance in this component?
A low equivalent series resistance improves the efficiency of power delivery and reduces heat generation, making it Ideal for applications requiring high-frequency operation.
How does the temperature rating impact performance in automotive applications?
The Ability to function within a broad temperature range ensures reliAbility in harsh automotive environments, contributing to the longevity and stAbility of onboard electronics.
What does the polarised design mean for circuit integration?
The polarised design ensures correct installation within circuits, allowing for optimal performance and preventing potential damage from incorrect connections.
