Panasonic 3.6 V WiFi Module, 802.11 b/g/n | ENW49D01A1KF

Name: Panasonic 3.6 V WiFi Module, 802.11 b/g/n | ENW49D01A1KF
SKU: 2650-422
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 9 pcs

Mfr. Part No: ENW49D01A1KF

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 2650-422 Categories: Panasonic, Wi-Fi Modules

Description

Specifications

Attribute	Value
Brand	Panasonic
Product Type	WiFi Module
Supported Security Standards	WPA2, WPA3
Output Power	18dBm
Data Rate	150Mbps
Frequency	2483.5MHz
Height	3.1mm
Length	24mm
Minimum Supply Voltage	3.3V
Width	13 mm
Maximum Supply Voltage	3.6V
Supported Protocols	802.11 b/g/n
Minimum Operating Temperature	-40°C
Maximum Operating Temperature	84°C
Standards/Approvals	No
Series	ENW49D01A1KF

Product Details

The 4MB Flash 2MB PSRAM version of the PAN9520. The PAN9520 is a 2.4 GHz 802.11 b/g/n embedded Wi‑Fi module based on Espressif’s ESP32-S2 that includes the powerful Xtensa® 32-bit LX7 CPU. An integrated chip antenna and QSPI memory enable the module to be used in a variety of stand-alone or host -controlled applications. The integrated crystal ensures connection performance over full temperature range and lifetime. Although the PAN9520 is one of the smallest modules on the market, this offers a rich set of peripherals like full-speed USB OTG, SPI, UART, I²C, and many more.
