Panasonic 560 μF Surface Mount Polymer Capacitor, 25 V | EEHZS1E561V
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 12 pcs
Mfr. Part No: EEHZS1E561V
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Panasonic |
| Technology | Hybrid |
| Product Type | Polymer Capacitor |
| Capacitance | 560μF |
| Voltage | 25 V |
| Mount Type | Surface Mount |
| Polarity | Polar |
| Lead Pitch | 11mm |
| Tolerance | ±20 % |
| Maximum Operating Temperature | 125°C |
| Dimensions | 11 x 10.3 x 16.5 mm |
| Depth | 10.3mm |
| Length | 11mm |
| Series | ZS |
| Height | 16.5mm |
| Electrolyte Type | Hybrid |
| Dissipation Factor | 0.14% |
| Automotive Standard | AEC-Q200 |
| Minimum Operating Temperature | -55°C |
| Lifetime | 4000 h |
| Diameter | 10 mm |
| Leakage Current | 140μA |
| Ripple Current | 4A |
Product Details
High ripple current and large capacitance compared with ZC series, anti vibration
High ripple current and Large capacitance compared with ZC series
Endurance: 4000 h at 125°C
Equivalent to conductive polymer type Aluminum Electrolytic capacitor(There are little characteristics change by temperature and frequency)
