Panasonic 68 μF Surface Mount Polymer Capacitor, 50 V | EEHZT1H680V
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 12 pcs
Mfr. Part No: EEHZT1H680V
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Panasonic |
| Product Type | Polymer Capacitor |
| Technology | Hybrid |
| Capacitance | 68μF |
| Voltage | 50 V |
| Mount Type | Surface Mount |
| Polarity | Polar |
| Lead Pitch | 4.6mm |
| Tolerance | ±20 % |
| Maximum Operating Temperature | 125°C |
| Dimensions | 8 x 10.5 mm |
| Length | 10.5mm |
| Series | ZT |
| Height | 12mm |
| Electrolyte Type | Solid |
| Lifetime | 4000 h |
| Leakage Current | 34μA |
| Ripple Current | 2.7A |
| Minimum Operating Temperature | -55°C |
| Automotive Standard | AEC-Q200 |
| Dissipation Factor | 10% |
| Diameter | 8 mm |
Product Details
The Panasonic ZT series V type uses hybrid technology. It has voltage rating of 50 V and capacitance of 68 uF with 125 °C maximum temperature range. It provides high safety with compact design. It has ESR value 25 mOhm with over all dimensions of 8×10.5 mm.
Endurance 4000 h at 125 ℃
Higher ripple current (75 % to 118 % higher than ZC series)
Vibration-proof product is available upon request.
AEC-Q200 compliant
RoHS compliant
