Panasonic 68 μF Surface Mount Polymer Capacitor, 6.3 V | EEFLR0J680R
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 8 pcs
Mfr. Part No: EEFLR0J680R
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Panasonic |
| Technology | Polymer |
| Product Type | Polymer Capacitor |
| Capacitance | 68μF |
| Voltage | 6.3 V |
| Mount Type | Surface Mount |
| Polarity | Polar |
| Tolerance | ±20 % |
| Maximum Operating Temperature | 105°C |
| Dimensions | 7.3 x 4.3 x 1 mm |
| Series | SP-CAP LR |
| Height | 1mm |
| Depth | 4.3mm |
| Length | 7.3mm |
| Electrolyte Type | Polymer |
| Dissipation Factor | 6% |
| Ripple Current | 6.3A |
| Leakage Current | 42.8μA |
| Automotive Standard | No |
| Minimum Operating Temperature | -55°C |
| Lifetime | 2000 h |
Product Details
SP-CAP Surface Mount Type L series
Panasonic Conductive Polymer Aluminium Capacitors, LX, LR, LS and LT series. These general purpose capacitors feature low ESR and ESL.
Features & Benefits:
Low profile (1.0mm (maximum), 1.1mm, 1.4mm height)
Low ESR: 4.5mΩ to 15mΩ (LR, LS and LT series) and 4.5mΩ to 15mΩ for LX series
Low ESL (3-terminals: 50% less than 2-terminals)
Large Capacitance up to 560μF for the LX series
