Panasonic 680 μF Surface Mount Polymer Capacitor, 6.3 V | 6TPE680MI
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 15 pcs
Mfr. Part No: 6TPE680MI
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Panasonic |
| Product Type | Polymer Capacitor |
| Technology | Polymer |
| Capacitance | 680μF |
| Voltage | 6.3 V |
| Mount Type | Surface Mount |
| Package/Case | D4 |
| Tolerance | ±20 % |
| Maximum Operating Temperature | 105°C |
| Dimensions | 7.3 x 4.3 x 3.8 mm |
| Series | POSCAP TPE |
| Depth | 4.3mm |
| Height | 3.8mm |
| Length | 7.3mm |
| Electrolyte Type | Solid |
| Ripple Current | 3500mA |
| Leakage Current | 428.4μA |
| Dissipation Factor | 15% |
| Minimum Operating Temperature | -55°C |
| Automotive Standard | No |
| Lifetime | 1000 h |
Product Details
POSCAP TPE series
Panasonic TPE series tantalum capacitors are part of the POSCAP range. Constructed from sintered tantalum as the anode material, the large surface area of the porous materials enables large capacitance. High in electric conductivity, the conductive polymer utilised for the electrolyte enables low ESR of 15 mΩ. TPE tantalum capacitors have high heat resistance and reliability making them suitable for high frequency and digital devices.
Small size
Solid electrolytic chip capacitors
Excellent frequency characteristics
Lower impedance compared to standard aluminium electrolytic and tantalum capacitors
Low ESR allows for a high ripple current rating compared to other electrolytic capacitors
Conductive polymer enables a self-healing mechanism
Tantalum oxide ensures that no vibration is generated and there is no noise on the PCB
Applications
Typical applications include backup and bypass capacitors for digital equipment and noise removal. These tantalum capacitors can be used in PCs, mobile phones, home appliances, automotive and industrial equipment.
