Panasonic Bluetooth Chip 4.2 | ENW89823A4KF

Name: Panasonic Bluetooth Chip 4.2 | ENW89823A4KF
SKU: 9091-471
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 7 pcs

Mfr. Part No: ENW89823A4KF

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 9091-471 Categories: Bluetooth Modules, Panasonic

Description

Specifications

Attribute	Value
Brand	Panasonic
Bluetooth Class	Class 1
Product Type	Bluetooth Chip
Bluetooth Version	4.2
Maximum Output Power	11.5dBm
Data Rate	2178kbps
Receiver Sensitivity	-93dBm
Frequency	2.48GHz
Minimum Supply Voltage	1.7V
Maximum Supply Voltage	4.8V
Minimum Operating Temperature	-45°C
Maximum Operating Temperature	85°C
Height	1.8mm
Length	9mm
Width	9.5 mm
Standards/Approvals	No

Product Details

Panasonic’s new PAN1326C is a Host Controlled Interface (HCI) Bluetooth RF module that brings Texas Instrument’s seventh generation Bluetooth core integrated circuit, the CC2564C, to an easy-to- use module format. The PAN1326C is Bluetooth-4.2 compliant and it offers best-in-class RF performance with about twice the range of other Bluetooth Low Energy solutions. Panasonic’s tiny footprint technology has produced a module of only 85.5 mm². The module is designed to accommodate PCBs pad pitch of 1.3 mm and as few as two layers for easy implementation and manufacturing.

Bluetooth-4.2-compliant up to the HCI layer

Best-in-class Bluetooth RF performance (Tx, Rx

sensitivity, blocking)

Dimensions: 9.0 mm x 9.5 mm x 1.8 mm

Based upon TI’s CC2564C

Interfaces: UART, GPIO, PCM

Bluetooth 4.2

Receiver sensitivity -93 dBm
