Panasonic Bluetooth Module 5.0 | ENW89854A3KF
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 6 pcs
Mfr. Part No: ENW89854A3KF
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Panasonic |
| Product Type | Bluetooth Module |
| Bluetooth Version | 5.0 |
| Data Rate | 2Mbps |
| Maximum Output Power | 8dBm |
| Receiver Sensitivity | -103dBm |
| Frequency | 2480MHz |
| Interface Type | USB 2.0, UART |
| Minimum Supply Voltage | 1.7V |
| Maximum Supply Voltage | 5.5V |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | 85°C |
| Height | 2mm |
| Width | 8.7 mm |
| Series | PAN1780‐AT |
| Standards/Approvals | No |
| Length | 15.6mm |
Product Details
The Panasonic PAN1780AT is a Bluetooth® 5 Low Energy Module based on the Nordic nRF52840 single-chip controller. The Bluetooth® 5 features enable a higher symbol rate of 2 Mbps using the high-speed LE 2M PHY. Furthermore, the new LE advertising extensions allow for much larger amounts of data to be broadcasted in connectionless scenarios. In addition to Bluetooth® 5, the qualified Bluetooth® mesh profile stack supports 802.15.4 and NFC-A. The PAN1780AT comes with AT Command Stack.
Surface mount type dimensions: 15.6?mm x 8.7?mm x 2?mm
Same footprint as PAN1780
Bluetooth 5 LE including LE 2M and LE
Embedded 1?MB flash memory and
256?kB internal RAM
Up to 46 General Purpose I/Os (GPIO), which are
shared with 1?UART, 8?ADC’s, 1 NFC-A, and
nRESET input
