Panasonic ERJ PA2 2.2 kΩ, 0402 Thick Film Surface Mount Fixed Resistor ±5 % Surface 0.2 W | ERJPA2J222X
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 4 pcs
Mfr. Part No: ERJPA2J222X
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Panasonic |
| Resistance | 2.2kΩ |
| Product Type | Surface Mount Fixed Resistor |
| Technology | Thick Film |
| Package/Case | 0402 |
| Tolerance | ±5 % |
| Packaging | Tape & Reel |
| Voltage | 50 V |
| Power Rating | 0.2W |
| Temperature Coefficient | 200 ppm/°C |
| Mount Type | Surface |
| Automotive Standard | AEC-Q200 |
| Pin Count | 2 |
| Series | ERJ PA2 |
| Minimum Operating Temperature | -55°C |
| Maximum Operating Temperature | 155°C |
| Height | 0.40mm |
| Width | 0.5 mm |
| Standards/Approvals | IEC 60115-8, JEITA RC-2134C, JIS C 5201-8 |
| Length | 1mm |
Product Details
The Panasonic Anti-Surge Thick Film Chip Resistors are designed to offer superior ESD (Electrostatic Discharge) surge protection compared to standard metal film resistors. With a metal glaze thick film resistive element and three layers of electrodes, they provide high reliability and stability under demanding conditions. These resistors are suitable for both reflow and flow soldering processes, making them versatile for various manufacturing environments.
AEC-Q200 compliant
RoHS compliant
