Panasonic PCB Signal Relay, 12 V dc Coil, 2 A, DPDT | TX2L12

Name: Panasonic PCB Signal Relay, 12 V dc Coil, 2 A, DPDT | TX2L12
SKU: 5898-371
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 14 pcs

Mfr. Part No: TX2L12

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 5898-371 Categories: Panasonic, Signal Relays

Description

Specifications

Attribute	Value
Brand	Panasonic
Product Type	Signal Relay
Coil Voltage	12 V dc
Contact Configuration	DPDT
Mount Type	PCB
Switching Current	2 A
Switching DC Voltage	220 V
Series	TX
Minimum Operating Temperature	-40°C
Switching Power	60W
Maximum Operating Temperature	85°C
Width	7.4 mm
Length	15mm
Height	8.2mm
Terminal Type	Through Hole
Standards/Approvals	RoHS
Coil Resistance	1.44kΩ
Contact Material	Gold Plated
Contact Resistance	100mΩ
Coil Power	100mW

Product Details

TX Series – Latching

These compact PCB mount relays have a 2 kV breakdown voltage between contact and coil and an outstanding surge resistance. These PCB relays also offer high contact capacity and reliability and excellent vibration and shock resistance. A sealed construction allows automatic washing. Typical applications include communications, measurement, security, automotive, audio visual and medical equipment and home appliances.

High sensitivity of 100mW / 200mW

High contact capacity, 2 A 30 Vdc
