Parker 5/2 Pneumatic Solenoid Valve – Pilot/Spring G 1/8 PVL Series | PVL-B121606
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 16 pcs
Mfr. Part No: PVL-B121606
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Parker |
| Function | 5/2 |
| Connection Port Thread | G 1/8 |
| Actuation Type | Pilot/Spring |
| Manufacturer Series | PVL |
| Mounting Style | Block, DIN Rail |
| Number of Ports | 5/2 |
| Body Material | Plastic |
| Maximum Flow Rate | 900L/min |
| Minimum Operating Pressure | 2bar |
| Thread Size | 6mm |
| Minimum Operating Temperature | -15°C |
| Maximum Operating Pressure | 10bar |
| Maximum Operating Temperature | +60°C |
| Thread Standard | G |
Product Details
PVL Manifold Valves
High Flow, compact and lightweight DIN-rail mounting, manifold valve system, 15mm pitch.
Integral 6mm Ø push-in connectors
Choice of solenoid or pilot operators
2 to 10 bar operating pressure (3 bar minimumfor spring-return operation)
DIN-rail or surface-block mounting
Choice of solenoid or pilot operators
2 to 10 bar operating pressure (3 bar minimumfor spring-return operation)
DIN-rail or surface-block mounting
Warning
Compressed air, while generally considered as a safe source of energy, must always be treated with caution and under no circumstances be used for any other purposes than that for which it is intended.
