Parker 5/2 Pneumatic Solenoid Valve – Solenoid/Spring G 1/8 Viking Xtreme Series | P2LAX511ESNDDN
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 15 pcs
Mfr. Part No: P2LAX511ESNDDN
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Parker |
| Function | 5/2 |
| Connection Port Thread | G 1/8 |
| Actuation Type | Solenoid/Spring |
| Manufacturer Series | Viking Xtreme |
| Number of Ports | 5/2 |
| Body Material | Anodised Aluminium |
| Maximum Flow Rate | 19L/min |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Pressure | 10bar |
| Maximum Operating Temperature | +60°C |
| Thread Size | 1/8in |
| Thread Standard | G |
Product Details
Parker Solenoid Directional Control Valve
The Parker Viking Xtreme series 5/2 ports directional control valve has a maximum flow rate of 19L/min. This valve has a 1/8in G port connection and electric signal type actuation with a spring return. It has a compact design and short change-over times. This control valve is suitable for use within a wide variety of temperature ranges.
Note:
For a suitable connector/plug, the following DIN 43650 Hirschmann screw-down connector may be used: 484-010
Note:
For a suitable connector/plug, the following DIN 43650 Hirschmann screw-down connector may be used: 484-010
Features and Benefits
Good corrosion resistance
Operating pressure ranges between 3.2bar and 10bar
Operating temperature ranges between -40°C and 60°C
Supplied with a 22mm solenoid operator less coil
Operating pressure ranges between 3.2bar and 10bar
Operating temperature ranges between -40°C and 60°C
Supplied with a 22mm solenoid operator less coil
