Patlite SL Series Blue Sounder Beacon, 12→24 VDC, IP66, Base Mount | SL08-M1KTB-B
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 9 pcs
Mfr. Part No: SL08-M1KTB-B
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Patlite |
| Supply Voltage | 12→24 VDC |
| Lens Colour | Blue |
| Mounting Style | Base Mount |
| Current Type | DC |
| Light Effect | Continuous, Blinking , Triple-flash |
| Sounder Type | Buzzer |
| Series | SL |
| Bulb Type | LED |
| Maximum Decibel | 86dB |
| IP Rating | IP66 |
| Number Of Tones | 1 |
| Maximum Temperature | +50°C |
| Standards Met | UL 508, CSA-C22.2 No.14, EN61000-6-4, EN61000-6-2, EN61000-3-2, EN61000-3-3, KN61000-6-4, KN61000-6-2, FCC Part15 SubpartB ClassA, ICES-003 ClassA, IEC/EN60947-5-1, EN62471, TPTC020/2011, TPTC004/2011 |
| Housing Material | Polycarbonate |
| Minimum Temperature | -20°C |
Product Details
The SL series blue colour flashing beacon with buzzer and size 80mm. It has an operating voltage rating of 12-24V dc. It is available with screw less terminal block.
Rotation Flashing Rate (Typ.) Blinking (180 flashes per minute), Triple Flash (120 flashes per minute)
Mounting Direction Indoor: Upright, Inverted, Sideways
Outdoor: Upright
Material (Glove / Body) PC
Sound Pressure Level (Typ.) 86dB
Mounting Direction Indoor: Upright, Inverted, Sideways
Outdoor: Upright
Material (Glove / Body) PC
Sound Pressure Level (Typ.) 86dB
