PCH Relay,1CO,10A 120ac,12dc 200mW | PCH-112L2M
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 6 pcs
Mfr. Part No: PCH-112L2M
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | TE Connectivity |
| Coil Voltage | 12V dc |
| Contact Configuration | SPNO |
| Switching Current | 10 A |
| Mounting Type | PCB Mount |
| Terminal Type | Through Hole |
| Coil Resistance | 720 Ω |
| Application | PCB |
| Length | 20mm |
| Depth | 10mm |
| Height | 15.2mm |
| Dimensions | 20 x 10 x 15.2mm |
| Maximum Operating Temperature | +85°C |
| Contact Material | Silver Alloy |
| Minimum Operating Temperature | -40°C |
| Operating Temperature Range | -40 → +85°C |
Product Details
TE Connectivity Miniature PCB Relay – PCH Series
PCH series miniature PCB through hole mount relays with SPST and SPDT AgSnO2 contacts. These miniature PCB through hole mount relays have washtight, sealed plastic covers apart from stock numbers 533-0867, 533-0867 and 533-0873 which have flux proof vented covers. PCB relays with SPST contacts have a senstive 200mW coil. Typical applications for these PCH series PCB relays include HVAC, refrigerators and microwave ovens.
High surge voltage capacity; 8000V (1.2/50μs)
Ambient temperature; -30 to +85°C
Contact rating: 5A @ 250Vac (IEC 61810), 10 A @ 125 Vac (UL 508)
Contact material; AgSnO
Dimensions (mm); H 15.2, W 9.9, D19.8
Ambient temperature; -30 to +85°C
Contact rating: 5A @ 250Vac (IEC 61810), 10 A @ 125 Vac (UL 508)
Contact material; AgSnO
Dimensions (mm); H 15.2, W 9.9, D19.8
Approvals
UL; CSA; VDE
Approvals
UL; CSA; VDE
