PCH Series Relay,1CO,10A 120ac,5dc 200mW | PCH-105L2M

Name: PCH Series Relay,1CO,10A 120ac,5dc 200mW | PCH-105L2M
SKU: 1580-335
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 13 pcs

Mfr. Part No: PCH-105L2M

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 1580-335 Categories: Power Relays, TE Connectivity

Description

Specifications

Attribute	Value
Brand	TE Connectivity
Coil Voltage	5V dc
Contact Configuration	SPNO
Mounting Type	PCB Mount
Switching Current	10 A
Terminal Type	Through Hole
Coil Resistance	125 Ω
Application	PCB
Length	20mm
Depth	10mm
Height	15.2mm
Dimensions	20 x 10 x 15.2mm
Contact Material	Silver Alloy
Operating Temperature Range	-40 → +85°C
Maximum Operating Temperature	+85°C
Minimum Operating Temperature	-40°C

Product Details

TE Connectivity Miniature PCB Relay – PCH Series

PCH series miniature PCB through hole mount relays with SPST and SPDT AgSnO₂ contacts. These miniature PCB through hole mount relays have washtight, sealed plastic covers apart from stock numbers 533-0867, 533-0867 and 533-0873 which have flux proof vented covers. PCB relays with SPST contacts have a senstive 200mW coil. Typical applications for these PCH series PCB relays include HVAC, refrigerators and microwave ovens.

High surge voltage capacity; 8000V (1.2/50μs)
Ambient temperature; -30 to +85°C
Contact rating: 5A @ 250Vac (IEC 61810), 10 A @ 125 Vac (UL 508)
Contact material; AgSnO
Dimensions (mm); H 15.2, W 9.9, D19.8
