Pepperl + Fuchs 2 Channel Zener Barrier, ATEX | Z787.F
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 4 pcs
Mfr. Part No: Z787.F
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Pepperl + Fuchs |
| Number of Channels | 2 |
| Product Type | Zener Barrier |
| Barrier Type | Zener Barrier |
| Mount Type | DIN Rail |
| Hazardous Area Certification | ATEX |
| Safety Current Resistance | 341Ω |
| Terminal Type | Screw |
| Supply Voltage | 27 V dc |
| IP Rating | IP20 |
| Maximum Safety Voltage | 250V |
| Maximum Safety Current | 93mA |
| Minimum Operating Temperature | -20°C |
| Maximum Operating Temperature | 60°C |
| Standards/Approvals | EN, CE, TUV, IEC |
| Series | Z787.F |
Product Details
Z954 Triple Channel
The above drawing shows a RTD temperature sensor in a 3-wire design that relay the measured temperature through a 4.5V 12Ω triple channel zener barrier. The entire system is quasi-floating. All three channels have an identical end to end resistance.Typical application – RTD temperature measuring devices
Isolation Barriers
Pepperl+Fuchs shunt zener diode barriers are for use as safety interfaces between intrinsically safe and non-intrinsically safe circuits. They are manufactured from Makrolon® and designed to conduct electrical signals – in either direction – between safe and hazardous areas and to limit the amount of energy which can be transferred from a safe to a hazardous area in the event of fault conditions occurring in the safe area. All systems shown are licensed for [EEx ia] IIC Class 1, Div1, Groups A-G
Group and Category
IIC Class 1, Div1, Groups A-G
Certificate No.
BAS 01 ATEX 7005
