Specifications
| Attribute | Value |
|---|---|
| Brand | Pepperl + Fuchs |
| Thread Size | M18 |
| Sensor Technology | Inductive |
| Detection Range | 8 mm |
| Body Style | Threaded Barrel |
| Digital Switching Output Type | NPN |
| Output Function | NO |
| Connection Type | M12 |
| Supply Voltage | 5 → 36 V dc |
| Length | 65mm |
| IP Rating | IP68 |
| Mounting Type | Non-Flush |
| Housing Material | Brass, White Bronze Coated |
| Maximum DC Voltage | 36V |
| Minimum Operating Temperature | -40°C |
| Short Circuit Overload Protection | Yes |
| Switching Frequency | 1.65 kHz |
| Reverse Polarity Protection | Yes |
| Shielding | Unshielded |
| Maximum Switching Frequency | 1.65kHz |
| Switching Current | 200 mA |
| Maximum Operating Temperature | +85°C |
| Depth | 18mm |
Product Details
Extended Sensing Range
Features and benefits
Embeddable or flush installation
IP67
Supply voltage 10 to 30Vdc
Short circuit and reverse polarity protection
Pre-wired types have 2m PVC cable
Plug-in types have M12 type V1 connector
