Pfannenberg FLZ NO Thermostat, 15 A, 120 V, 60 °C, 0 °C | 17121001000
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 7 pcs
Mfr. Part No: 17121001000
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Pfannenberg |
| Product Type | Thermostat |
| Sub Type | Thermostat |
| Contact Voltage | 120V |
| Switch Configuration | NO |
| Supply Voltage | 120 V |
| Maximum Operating Temperature | 60°C |
| Minimum Operating Temperature | 0°C |
| Contact Current | 15A |
| Standards/Approvals | RoHS, EN 60715 |
| Series | FLZ |
| Special Features | Heating Control |
| Temperature Setting Range | 0 to 60 °C |
Product Details
The Pfannenberg Thermostats are used as temperature regulators and thus to control filterfans, electrical cabinet heaters or can serve as an alarm setpoint. They are available as N.C. / N.O. and changeover contacts. In combination with electrical cabinet heaters, they can control temperature and also, particularly in outdoor applications, ensure that the electrical cabinet is ‘artificially’ dehumidified. This means that the temperature is kept over the dew point so that no condensation forms from the air preventing a potential short circuit. The combination with filterfans provides additional savings on energy, maintenance time and therefore provides a better environmental balance which improves the filterfans effectiveness. The twin thermostat series combines two thermostats in all combinations for complex switching tasks.
Suitable for the operation of fans
Switching temperature difference <7K
Switching point tolerance +/4K
Temperature set range 0C to 60C
FLZ510: Changeover switch with spring contact
FLZ520: N.C. with spring contact (suitable to control heaters)
FLZ530: N.O. with spring contact (suitable to control fans)
FLZ541: N.C. and N.O. with spring contact in one housing
FLZ542: N.C. and N.C. with spring contact in one housing
FLZ543: N.O. and N.O. with spring contact in one housing
Is suitable for all industrial applications
No influence due to EM radiation, because a contact that switches mechanically is integrated
Extends the service life of heaters and fans
Optimized energy consumption for heaters and filterfans
Easy installation on profile rails
Electrical connection via screw terminals
IP 20 protection for installation inside the electrical cabinet
Approvals: cURus, EAC, CSA
