Pfannenberg PY X-S-05 Series Red Flashing Beacon, 24 V dc, Panel Mount, Xenon Bulb | 21510805000
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 15 pcs
Mfr. Part No: 21510805000
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Pfannenberg |
| Supply Voltage | 24 V dc |
| Light Effect | Flashing |
| Lens Colour | Red |
| Mounting Style | Panel Mount |
| Bulb Type | Xenon |
| Current Type | DC |
| Housing Colour | Red |
| Lamp Included | Yes |
| Series | PY X-S-05 |
| Height | 80.6mm |
| Base Length | 109.5mm |
| Maximum Temperature | +55°C |
| Base Width | 85.8mm |
| Minimum Temperature | -40°C |
Product Details
Pfannenberg PYRA Compact Flashing Beacons, PY X-S-05
The PYRA PY X-S-05 is a compact flashing xenon beacon that can be used for many applications and is safe and simple to mount.
Rectangular PC/ABS blend housing with PC lens
Installation options with external lugs or internal holes
Simple electrical connection on the bottom of the casing
Impact-proof lens
Suitable for panel mounting
Red and grey housing
Housing can be easily stacked side-by side thanks to modular design
Visual covering distance 11 m
IK08 Impact-proof housing
IP66 protection according to EN 60529
5J flash
10 year warranty
Installation options with external lugs or internal holes
Simple electrical connection on the bottom of the casing
Impact-proof lens
Suitable for panel mounting
Red and grey housing
Housing can be easily stacked side-by side thanks to modular design
Visual covering distance 11 m
IK08 Impact-proof housing
IP66 protection according to EN 60529
5J flash
10 year warranty
Note
Only stock nos. 846-3529 and 846-3538 comply with EN 54-23.
Approvals
UL, GL, VdS, EN 54-23.
