Phoenix Contact Distribution Block, 7 Way, 690 V, 24A, Red | 1019544
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 13 pcs
Mfr. Part No: 1019544
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Phoenix Contact |
| Number of Ways | 7 |
| Product Type | Distribution Block |
| Current | 24A |
| Housing Material | Polyamide |
| Voltage | 690 V |
| Termination Type – Line Side | Push-in |
| Connections Per Pole – Line Side | 7 |
| Connections Per Pole – Load Side | 7 |
| Minimum Operating Temperature | -60°C |
| Wire Size – Line Side | 26/14 AWG |
| Termination Type – Load Side | Push-in |
| Colour | Red |
| Height | 29.2mm |
| Maximum Operating Temperature | 105°C |
| Length | 45.7mm |
| Series | PTVFIX |
| Width | 26 mm |
| Standards/Approvals | RoHS, CSA |
Product Details
The Phoenix Contact Distribution block has nominal voltage of 690 V, nominal current 24 A and connection method is of push-in connection type. This has rated cross section of 2.5 mm².
Cross section is 0.14 mm² to 4 mm²
Mounting type is NS 35/7,5, NS 35/15
