Phoenix Contact OPT Series Solid State Relay | 2967950

PLC Interface single- and double-pole relays, and opto-couplers, having the same profile. This allows the modules to be installed in any configuration with a common bridging system and using the same accessories. The V8 adapter connects 8 relays or opto-couplers to a 15 way D-SUB cable.

• Relays and opto-couplers for inputs and outputs with “pluggable” switching devices
• Four bridging slots to reduce wiring; bridging of up to 80 modules is possible
• Screw terminal connections
• LED indicators and diodes for coil suppression
• 250V versions have a switched power rating of 1500VA
• Mechanical life (relays) 1 x 107 operations
• Wide range of accessories also available

This solid state relay is designed for efficient and reliable switching applications in various industries. It is a PCB mounted relay with a compact design, measuring 28 x 5 x 15mm, making it suitable for tight spaces. This type of relay operates with a control voltage range of 19.2 to 28.8V and is ideal for DC switching tasks.

• SPST configuration facilitates simple on/off control
• High-temperature operation up to +60°C ensures reliability
• Off-state leakage current of only 1 mA reduces energy loss
• Turn-on time of just 6 ms improves responsiveness in systems
• Designed for through-hole mounting enhances installation flexibility
• Minimum load current of 10mA ensures efficient operation

• Used for automation control in industrial machinery
• Ideal in electronic circuits requiring fast switching
• Employed in motor control and lighting systems
• Suitable for high-temperature environments in manufacturing

The effective control voltage range for this relay spans from 19.2V to 28.8V, ensuring it can accommodate various control signal requirements for electronic and automation tasks.

The relay can operate in temperatures ranging from -25°C to +60°C, making it suitable for high-temperature ambient conditions in diverse applications without risking failure or performance degradation.

The short turn-on time of 6 ms allows for rapid response in systems, making this relay ideal for applications where immediate switching is critical, such as in automation or signal processing.
