Phoenix Contact PCB Mount Power Relay, 12V dc Coil, 8A Switching Current, DPDT | 2961257

Phoenix contacts REL-MR series of non-latching relays are commonly found within industrial environments, they are considered to be electrical and mechanical devices. This type of relay can often be referred to an electromechanical relay or an industrial switch.

• Pluggable miniature relays, with power contact for high continuous current
• Varied switching current dependant on the relay chosen from the REL-MR series
• Pluggable miniature relay – compact in size
• Additional hard gold plating
• AC and DC coil voltages
• Robust and hard wearing

A relay is an electrical switch that is operated by electrical pulses, their primary function is to open and close a circuit. When power passes through a circuit, a relay switches position (usually from NC to NO) using an internal coil which generates a magnetic force. This force then holds the relay in a NO position, when the current is switched off the relay returns to the NC position. This function is what makes these non-latching relays perfect for push-button applications such as keyboards and micro-controller input buttons.

Non-latching relays support a range of signal characteristics, ranging from low voltage or current to high voltage or current and from DC to GHz frequencies.

• When a latching relay operates its contacts, the relay holds its position, even when the supply of its operating coil has been disconnected.
• When a non-latching relay operates its contacts, the relay will reset automatically once the supply of its coil is disconnected through the internal spring mechanism.

  IEC 60255, EN 50178, EN 60730, IEC 60664

  DIN VDE 0435, DIN VDE 0160, DIN VDE 0631, DIN VDE 0110

This non-latching relay from Phoenix Contact is ideal for creating a push-button application like a keyboard or doorbell. It uses an electric current to open and close a circuit. When power passes through the switch, an internal coil holds the relay open. The circuit closes again once the current is disconnected.
The relay has silver-alloy contacts, offering excellent electrical conductivity for an efficient signal and resistance to corrosion for a long working life. The switch is also robust and hard-wearing, so you can be sure of its reliability even with frequent use.
This product is designed for a switching current of 8 A. As it’s compact, it won’t take up too much space in your circuit. You can mount it directly onto your printed circuit board (PCB).

• Double pole double throw (DPDT) contact configuration
• Through-hole terminal type
• Dimensions of 12.7 (length) x 29 (height) x 15.7 mm (depth)
• Coil resistance of 360 Ω
• Coil voltage of 12 V (DC)
• Maximum switching power (AC) of 2 kVA
• Maximum switching power (DC) of 190 W
• Maximum switching voltage (AC) of 250 V
• Maximum switching voltage (DC) of 250 V
• Operating temperature range of -40°C to +85°C
