Phoenix Contact PCB Mount Relay, 24V dc Coil, 5mA Switching Current, DPDT | 2903660
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 12 pcs
Mfr. Part No: 2903660
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Phoenix Contact |
| Coil Voltage | 24V dc |
| Contact Configuration | DPDT |
| Mounting Type | PCB Mount |
| Switching Current | 5mA |
| Number of Poles | 2 |
| Latching | No |
| Series | REL-IR2/LDP- 24DC/2X21 |
| Terminal Type | Plug In |
| Maximum Switching Voltage AC | 250V ac |
| Maximum Switching Voltage DC | 250V dc |
| Length | 21.2mm |
| Coil Resistance | 640Ω |
| Coil Power | 77mW |
| Height | 27.5mm |
| Life | 20000000 (Mechanical) cycles |
| Depth | 35.6mm |
| Maximum Operating Temperature | +70°C |
| Minimum Operating Temperature | -40°C |
| Standards Met | IEC 60664, IEC 61810 |
| Contact Material | Silver Alloy |
| Maximum Switching Power DC | 288 W |
| Width | 21.2mm |
| Maximum Switching Power AC | 3 kVA |
| Dimensions | 21.2 x 27.5 x 35.6mm |
| Application | Power |
Product Details
Phoenix Contact REL-IR2/LDP- 24DC/2X21 Series Relay, DPDT Contact Configuration, 24V DC Coil Voltage – 2903660
This relay is a plug-in device designed for automation and control applications operating at a coil voltage of 24V DC and features a double-pole double-throw (DPDT) configuration. Compactly designed with dimensions of 21.2×27.5×35.6mm, this PCB mount relay is equipped with power contacts for dependable switching in various environments.
Features & Benefits
• Operates within a temperature range of -40 to +70°C for flexibility
• Offers a mechanical life of approximately 20 million cycles for longevity
• Provides a maximum switching voltage of 250V AC/DC for diverse applications
• Incorporates a freewheeling diode for circuit protection
• Features a yellow LED status display for real-time operation feedback
• Utilises AgNi contact material for enhanced conductivity and durability
• Offers a mechanical life of approximately 20 million cycles for longevity
• Provides a maximum switching voltage of 250V AC/DC for diverse applications
• Incorporates a freewheeling diode for circuit protection
• Features a yellow LED status display for real-time operation feedback
• Utilises AgNi contact material for enhanced conductivity and durability
Applications
• Suitable for requiring consistent control in industrial settings
• Employed in machinery for automation and safety interlocks
• Utilised in control panels for electrical switching tasks
• Applicable in power distribution and management systems
• Employed in machinery for automation and safety interlocks
• Utilised in control panels for electrical switching tasks
• Applicable in power distribution and management systems
Is it suitable for harsh environments?
Yes, it meets IEC standards for operation in corrosive environments.
Can it handle high inrush currents?
Yes, it supports up to 30A for short durations.
Will it function with a different input voltage?
No, it operates optimally within the specified 24V DC range.
What type of contacts does it have?
It features two changeover contacts for flexible switching options.
