Phoenix Contact PLC-RSC- 24DC/21-21AU/MS Series Interface Relay, DIN Rail Mount, 24V dc Coil, DPDT, 2-Pole | 2910507
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 7 pcs
Mfr. Part No: 2910507
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Phoenix Contact |
| Coil Voltage | 24V dc |
| Contact Configuration | DPDT |
| Mounting Type | DIN Rail |
| Series | PLC-RSC- 24DC/21-21AU/MS |
| Number of Poles | 2 |
| Maximum Input Voltage | 24V dc |
| Terminal Type | Screw |
| Switching Voltage | 250V ac/dc |
| Depth | 104mm |
| Height | 80mm |
| Length | 14mm |
| Contact Material | Au, Silver Alloy |
| Input Current | 18mA |
| Life | 5 x 10^6 (Mechanical) cycles |
| Operating Temperature Range | -20 → +60°C |
| Dimensions | 14 x 104 x 80mm |
| Minimum Operating Temperature | -20°C |
| Maximum Operating Temperature | +60°C |
| Relay Switching Classification | Interface Relay Module |
| Standards Met | cUL 508 Recognized, EN 50178, UL 508 Recognized |
| Special Features | IP20 Relay Base |
Product Details
A 6.2 mm PLC interface relay module designed to be mountable on DIN rail NS 35/7.5. Featuring a basic terminal block with screw connection and a plug-in miniature power relay.
Phoenix Contact PLC-RCS Relays Series
This range of compact PLC relays from Phoenix Contact gives you a great choice of easy connection technology. The electromechanical relays act as the interface between your automation equipment and system peripherals.
Features and Benefits:
• Saves space on the DIN rail
• Cost-effective
• Use the same electromechanical relay module design for both AC and DC switching voltage
• DIN rail mounting
• SPNO and SPDT models available
• Yellow LED operating voltage display
• Free-wheeling diode Damping diode
• Dimensions 94 x 80 x 6.2 mm
• Cost-effective
• Use the same electromechanical relay module design for both AC and DC switching voltage
• DIN rail mounting
• SPNO and SPDT models available
• Yellow LED operating voltage display
• Free-wheeling diode Damping diode
• Dimensions 94 x 80 x 6.2 mm
Typical Applications:
The PLC relays are used in many different applications not limited to power amplification, electrical isolation or for using for voltage adjustment of frequency varying voltage levels.
PLC-RSC- 24DC/21-21AU/MS 2910507
PLC-INTERFACE, consisting of a relay base and pluggable power contact relay with manual operation, integrated status LED and free wheeling diode, Screw connection, 2 PDT, Input voltage: 24 V DC
