Phoenix Contact Polycarbonate Raspberry Pi Case for use with Enclosures, Boxes & Cases in Grey | 2202951

The RPI-BC enclosure from Phoenix Contact is designed to house a Raspberry Pi model A+, B+, B2 or B3. It features tool-free mounting and complies with DIN 43880 enabling it to be integrated in a distributor housing. The RPI-BC housing system can be mounted on a TS 35 DIN Rail or on a wall.

RPI-BC 107,6 DEV-KIT KMGY (stock no. 122-4298)

A lower housing part (for Din Rail or wall mounting), base latch, upper housing part, housing cover and PCB holder for mounting the Raspberry Pi board

Light grey

BC 107,6 UT HBUS KMGY (stock no. 122-4305)

A lower housing part and base latch (for Din Rail or wall mounting)

Light grey

RPI-BC 107,6 DEV-KIT KMGY P10 (stock no. 122-4299)

An upper housing part and PCB holder for mounting the Raspberry Pi board

Light grey

RPI-BC A+-ADAPTER ATGY (stock no. 122-4300) – an adapter for mounting the Raspberry Pi A+ model

RPI-BC EXT-PCB HBUS SET (stock no. 122-4304) a Perfboard and pin strip for connecting to the DIN Rail HBus connector

RPI-BC INT-PCB SET (stock no. 122-4303) a Perfboard, includes socket strips for the GPIO connection, solder rings for PTSM header, includes PTSM plugs and headers

PSTD 0,65X0,65/40-2,54 (stock no. 122-4301) a socket strip for connecting the RPI-BC INT-PCB SET Perfboard (or another additional PCB) to the GPIOs of the Raspberry Pi computer

PSTD 0,65X0,65/18-3IS-2,54 (stock no. 122-4302) a pin strip for connecting the RPI-BC EXT-PCB HBUS SET Perfboard (or another additional PCB) to the DIN Rail HBus connector

Further PCBs can also be inserted in the housing in addition to the Raspberry Pi board.
