Phoenix Contact PSR Series Input/Output Module, 8 Outputs, 24 V | 1105132
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 3 pcs
Mfr. Part No: 1105132
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Phoenix Contact |
| Series | PSR |
| Product Type | Input/Output Module |
| Sub Type | Extension Module |
| Mount Type | Extension Module |
| For Use With | Safety Modules |
| Supply Voltage | 24 V |
| Number of Outputs | 8 |
| Power Rating | 0.48W |
| Terminal Type | Screw |
| Standards/Approvals | UL Listed/cUL Listed/cULus Listed |
| Hazardous Area Certification | UL, cULus, cUL |
Product Details
The Phoenix Contact safe extension module provides the system additional safe outputs as well as signal outputs. It makes it possible to cost-effectively implement small applications with three safety functions as well as applications with up to 160 I/Os. In addition to monitoring classic safety functions, such as emergency stop signals, safety door locks, light grids, and safety shut-off mats, safety functions such as speed, zero-speed, or direction of rotation and safe analog value monitoring can also be implemented. The system is intended for machines and process applications up to PL e or SIL 3.
Economical safety solution with a high level of adaptability to individual requirements
Fast startup, thanks to easy hardware and software configuration
Machine downtime minimized with comprehensive, easy-to-understand diagnostics
Suitable for lift applications according to EN 81-20
Narrow housing width of just 22.6 mm
