Pico Technology Terminal Board for Use with Multi-Channel Data Logger | PP604

Connects to DB25 connector on PicoLog 1000 Series loggers

Screw terminals allow connection to each analogue and digital channel

Prototyping area for custom signal conditioning

Compatible with the PicoLog 1012,1216 ADC11/10 & ADC11/12 dataloggers

Easy to use PC-based data acquisition products that plug into a USB port on your PC (desktop or laptop) and require no power supply. Replacing costly chart recorders and complicated “plug in” data acquisition boards, these instruments allow your computer to display and record voltages. By connecting suitable sensors they can be used to measure temperature, pressure, humidity, light levels, current, power, speed, vibration, oxygen content and other signals.

Measures and logs temperature, pressure, humidity, light resistance, current, power, speed, vibration, oxygen levels & other signals depending on unit chosen, please see data sheets.

PicoLog software can collect data at rates from 1000 per second (depending on the speed of your computer and the operating system) to once per hour; up to 1 million samples can be collected

Data can be displayed in both graphical or spreadsheet format both during and after data collection

Programmable alarm limits can be set for each channel

PicoLog can collect data from multiple converters at the same time. This not only allows a mix of these voltage inputs units to be used on the same PC, but also allows other PC based instruments such as the TC-08 (temperature measurement) and the ADC-200 oscilloscope to be used at the same time

For users who wish to write their own software, drivers and examples are available for C, Pascal, Delphi, Visual Basic, HP VEE and LABVIEW.
