Red Lion Counter, 8 Digit LCD, 20kHz, 9 → 28 V dc | CUB5R000

Name: Red Lion Counter, 8 Digit LCD, 20kHz, 9 → 28 V dc | CUB5R000
SKU: 5237-294
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 6 pcs

Mfr. Part No: CUB5R000

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 5237-294 Categories: Counter ICs, Red Lion

Description

Specifications

Attribute	Value
Brand	Red Lion
Supply Voltage	9 → 28 V dc
Count Mode	Seconds
Display Type	LCD
Function	Counter
Input Type	Voltage
Connection Type	Screw
Reset Method	Manual
Number of Digits	8
Mounting Type	Panel Mount
Output / Interface	Relay
Count Direction	Bi-Directional
Digit Height	11.7 mm
Maximum Count Frequency	20kHz
Display Range	-9999999 → 9999999
Weight	100g
Maximum Temperature	+75°C
Measurement Range	-9999999 → 9999999
Maximum Operating Temperature	+75°C
Minimum Operating Temperature	-35°C

Product Details

Red Lion Digital Counter

The Red Lion CUB5 series digital dual counter and rate indicator is an 8-digit, reflective LCD display miniature electronic device. It has a voltage rating ranges between 9VDC and 28VDC. The intensity of this display can be adjusted from dark room applications to bright light applications. This easy to read display offers 12mm character height. The CUB5 models cover both, digital and analogue signals including count, voltage, current, time, process, rate and temperature inputs. This counter has a maximum count frequency of 20KHz.

Features and Benefits

Anti-coincidence counting (add/add and add/sub)
Relay output
Programmable scaling for count/rate
Display colour available in red and green
Bi-directional counting, up/down control
Resettable display
Panel cut-out dimensions are 68mm x 33mm
Plug-in screw terminal
Communication option cards include RS-232, RS-485, and USB
Operating temperature ranges between -35°C and 75°C
