Relpol PCB Mount Power Relay, 230V ac Coil, 8A Switching Current, DPDT | RM84-2012-35-5230
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 13 pcs
Mfr. Part No: RM84-2012-35-5230
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Relpol |
| Coil Voltage | 230V ac |
| Contact Configuration | DPDT |
| Mounting Type | PCB Mount |
| Switching Current | 8A |
| Number of Poles | 2 |
| Latching | No |
| Terminal Type | Plug In |
| Maximum Switching Voltage AC | 440V |
| Maximum Switching Voltage DC | 24V dc |
| Length | 29mm |
| Coil Resistance | 38500Ω |
| Coil Power | 750mW |
| Contact Material | Silver Alloy |
| Standards Met | CSA, cULus, EAC, PN-EN 60335-1, VDE |
| Minimum Operating Temperature | -40°C |
| Series | RM84 |
| Height | 15.7mm |
| Maximum Operating Temperature | +70°C |
| Isolation Coil To Contact | 5kV ac |
| Life | >100000 (Electrical) cycles, >30000000 (Mechanical) cycles |
| Depth | 12.7mm |
| Maximum Switching Power AC | 2 kVA |
Product Details
Relpol RM84 Series Miniature Relays
Relpol RM84 series miniature industrial relays for general purpose applications. All relays are designed for PCB mounting or in plug-in sockets.
Miniature dimensions
Cadmium-free contacts
AC and DC coils
RoHS compliant
Cadmium-free contacts
AC and DC coils
RoHS compliant
