Renold 06B-1 1 Roller Chain, 5 m, 13.2 mm, Renold SD, BS | SD06B1X5M
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 4 pcs
Mfr. Part No: SD06B1X5M
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Renold |
| Chain Type | 06B-1 |
| Product Type | Roller Chain |
| Pitch | 9.525mm |
| Number of Strands | 1 |
| Material | Steel |
| Series | Renold SD |
| Chain Standard | BS |
| Length | 5m |
| Pin Length | 13.2mm |
| Plate Height | 8.2mm |
| Roller Diameter | 6.35mm |
| Width Between Roller Link Plates | 5.72mm |
| Chain Weight | 0.4kg/m |
| Standards/Approvals | British/European |
Product Details
European (BS) Standard/ISO 606
Range of Renold SD economy Simplex roller chain, for standard duty applications. Conforms to European (BS) standards
Chain Standards
European standard chains are covered by DIN8187 and ISO606 standards. There are 3 versions:
• Simplex;• Duplex;• Triplex
Pitch size varies between 4 mm to 114.3 mm, with the chain links having a large pin diameter. The chains therefore have better wear resistance due to the bearing area being of a greater size.
The ISO standard has a simple numbering system:
• The first two digits are the pitch size and are measured in 1/16 s of an inch, for example 08 = 8/16;• “B” indicates European Standard;• The suffix indicates the number of strands in a chain
