Samtec 10-Way IDC Connector for Surface, 2 Row | FFSD-05-01-N
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 8 pcs
Mfr. Part No: FFSD-05-01-N
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Samtec |
| Product Type | IDC Connector |
| Number of Contacts | 10 |
| Number of Rows | 2 |
| Current | 2.3A |
| Pitch | 1.27mm |
| Mount Type | Surface |
| Orientation | Straight |
| Contact Plating | Gold or Tin over Nickel |
| Termination Type | IDC |
| Series | FFSD |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | 105°C |
| Standards/Approvals | RoHS, UL |
| Contact Material | Beryllium Copper Alloy |
| Housing Material | Polybutylene Terephthalate |
Product Details
.050″ (1.27 mm) pitch
All common pin counts from 3 to 25
High-reliability Tiger Eye™ contacts
Mating shrouded terminal strips and ejector headers
Optional strain relief
Polarization key
Wide variety of wiring options including reverses, daisy chains, etc.
