Schneider Electric 2-Axis Joystick Switch Lever, Spring Return, IP66 600V | XD5PA22
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 15 pcs
Mfr. Part No: XD5PA22
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Schneider Electric |
| Series | Harmony XD5 |
| Number of Axes | 2 |
| Switch Technology | Spring Return |
| IP Rating | IP66 |
| Handle Type | Lever |
| Contact Voltage Rating | 600V |
| Contact Current Rating | 220 mA |
| Contact Configuration | SPST |
| Contact Material | Silver Nickel |
| Terminal Type | Screw |
| Mechanical Life | 1000000Cycles |
| Minimum Operating Temperature | -40°C |
| Better World Verification | Green Premium |
| Maximum Operating Temperature | +70°C |
| Better World Product | Yes |
| Operating Temperature Range | -25 → +70°C |
Product Details
Schneider Electric Harmony XD5 Series Joystick Switch, Spring Return Switch Technology, Lever Handle – XD5PA22
This joystick switch is designed for precise control in a variety of automation and industrial applications. Its robust design and spring return functionality ensure seamless operation, making it an essential component for those in the electronics and mechanical sectors. The device is built to endure tough environments, guaranteeing reliability and effectiveness under demanding conditions.
Features & Benefits
• 2-axis configuration enhances multi-directional control
• Spring return mechanism provides an automatic reset to neutral
• IP66 rating offers dust and water protection
• Silver nickel contact material ensures high conductivity and durability
• Mechanical life rated at 1,000,000 cycles supports long-term use
• Screw clamp terminals simplify wiring for installation
• Spring return mechanism provides an automatic reset to neutral
• IP66 rating offers dust and water protection
• Silver nickel contact material ensures high conductivity and durability
• Mechanical life rated at 1,000,000 cycles supports long-term use
• Screw clamp terminals simplify wiring for installation
Applications
• Used for controlling machinery in manufacturing environments
• Suitable for vehicles requiring operator directional control
• Implemented in robotic systems for improved manoeuvrability
• Employed in automated assembly lines for precise operations
• Suitable for vehicles requiring operator directional control
• Implemented in robotic systems for improved manoeuvrability
• Employed in automated assembly lines for precise operations
What is the operational temperature range for this device?
The operational temperature range is between -25°C and +70°C, making it suitable for various environmental conditions.
How does the joystick support compatibility with different systems?
The joystick features screw clamp terminals that accommodate cables up to 1.5mm², facilitating easy integration into most electrical systems.
What kind of maintenance is required for ensuring longevity?
Regular inspection for wear on the operational shaft and keeping the unit free from contaminants can help maintain its functionality and lifespan.
Is the joystick resistant to pressure washing?
Yes, it can withstand high-pressure washing, rated at 7000000Pa at 55°C, making it appropriate for cleaning in industrial settings.
How is the joystick switch certified for safety?
The device complies with various international standards, ensuring it meets both safety and operational reliability criteria for industrial applications.
