Schneider Electric Digital Acti9 Time Switch, 1-Channel 230 V | CCT15858
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 13 pcs
Mfr. Part No: CCT15858
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Schneider Electric |
| Product Type | Time Switch |
| Sub Type | Digital |
| Number of Channels | 1 |
| Units Measured | Weekly |
| Segment Length | 1s |
| Terminal Type | Screw |
| Maximum Supply Voltage | 230V |
| Height | 92.6mm |
| Depth | 66.7mm |
| Standards/Approvals | EN 60730-2-7:2010 |
| Series | Acti9 |
Product Details
The Schneider Electric Programmable Time Switch featuring a backlit LCD display and four push buttons, this smart device offers efficient weekly programming with the added convenience of random programs. The switch ensures precision and reliability with two 0.5 to 2.5 mm² screw terminals for solid or flexible wiring and an additional 2.5 mm² terminal with a sleeve. Mounted on a TH35 DIN rail, conforming to EN 60715 standards. Notably, it incorporates advanced features such as pulse programming, a random function, and an external input for override, making it an ideal solution for diverse applications.
Mercury free
RoHS compliant
IP20 degree of protection
Sustainable green Premium product
