Schneider Electric Harmony XB4 Series Illuminated Illuminated Push Button, Spring Return, Flush, 22.5 mm Cutout, 1 NO, | XB4BW35B1
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 16 pcs
Mfr. Part No: XB4BW35B1
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Schneider Electric |
| Product Type | Illuminated Push Button |
| Actuator Colour | Orange |
| Switch Operation | Spring Return |
| Illuminated | Yes |
| Series | Harmony XB4 |
| Panel Cutout Size | 22.5 mm |
| Mount Type | Flush |
| Contact Configuration | 1 NO |
| LED Colour | Orange |
| Terminal Type | Screw Clamp |
| IP Rating | IP66, IP67, IP69, IP69K |
| Minimum Operating Temperature | -40°C |
| Contact DC Voltage | 24V dc |
| Contact AC Voltage | 24V ac |
| Actuator Style | Flush |
| Switch Configuration | 1 NO |
| Maximum Operating Temperature | 70°C |
| Standards/Approvals | CSA C22.2 No. 14, IEC 60947-1, IEC 60947-5-1, IEC 60947-5-4, IEC 60947-5-5, JIS C8201-1, JIS C8201-5-1, UL 508 |
| Width | 30 mm |
| Height | 47mm |
| Length | 101mm |
Product Details
The Schneider Electric Illuminated push button is an orange, flush-mounted complete unit, featuring a 22 mm spring-return operator with a plain lens design. It includes a protected LED light source for 24 V AC/DC operation and a slow-break contact configuration (1 NO), ensuring reliable signaling. Built with chromium-plated metal and Zamak material, it adheres to IEC standards and provides durability for industrial applications.
IP66 and IP67 protection
RoHS compliant
REACH compliant
