Specifications
| Attribute | Value |
|---|---|
| Brand | Schneider Electric |
| Supply Voltage | 100 → 230 V ac |
| Light Effect | Flashing, Rotating |
| Lens Colour | Red |
| Mounting Style | Base Mount |
| Bulb Type | LED |
| Current Type | AC |
| Base Diameter | 100mm |
| Housing Colour | Black |
| Lamp Included | Yes |
| Series | Harmony XVR |
| Multifunction | Yes |
| Height | 139mm |
| Base Length | 100mm |
| Better World Verification | Green Premium |
| Better World Product | Yes |
| IP Rating | IP23, IP65 |
| Maximum Temperature | +50°C |
| Base Width | 100mm |
| Special Features | Installation is Made Easy with a Flexible Voltage Input and Light Mode Selector, The Harmony XVR Range are Visual and Audible Signaling Units Mainly Used for Factory Applications, Construction Vehicles, and in Public Areas |
| Minimum Temperature | -10°C |
Product Details
Schneider XVR Multi-functional LED Beacons
Rotating, blinking, and flashing LEDs
10 lighting modes make it easy to use and simple to select
Wide voltage input to meet different applications
Straight and side wiring possible
Simple and easy installation without use of any tools
Available in green, red, orange and blue
Unique aesthetic design
Faceted lens extends the lighting area
Integrated rubber base improves the IP rating
Up to IP65 degree of protection depending on buzzer option
High vibration resistance of 7.1G
CE certified and RoHS compliant
Connection is via 400 mm flying leads with a cross-section of 0.57 mm2
