Sensata Crydom 1 Series Solid State Relay, 50 A rms Load, Panel Mount, 280 V rms Load, 280 V rms Control | A2450PG
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 3 pcs
Mfr. Part No: A2450PG
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Sensata / Crydom |
| Maximum Load Current | 50 A rms |
| Mounting Type | Panel Mount |
| Maximum Load Voltage | 280 V rms |
| Minimum Load Voltage | 24 V ac/dc |
| Maximum Control Voltage | 280 V rms |
| Minimum Control Voltage | 90 V ac/dc |
| Switching Type | Zero Cross |
| Control Voltage Range | 90 → 280 V ac |
| Minimum Load Current | 40 mA |
| Number of Poles | 1 |
| Terminal Type | Screw |
| Output Device | SCR |
| Relay Type | Solid State Relay |
| Maximum Turn On Time | 0.01 ms |
| Series | 1 |
| Load Voltage Range | 24 → 280V ac |
| Dimensions | 58.4 x 45.7 x 22.9mm |
| Height | 22.9mm |
| Capacitance | 8pF |
| Depth | 45.7mm |
| Special Features | AC or DC Control, Epoxy Free Design, Redesigned Housing with Anti-rotation Barriers |
| Standards Met | CE, CSA |
| Length | 58.4mm |
| Off State Leakage Current | 10 mArms |
| Minimum Operating Temperature | -40°C |
| Operating Temperature Range | -40 → +80°C |
| Maximum Operating Temperature | +80°C |
Product Details
Sensata | Crydom Solid-State Relay, 4000Vrms Dielectric Strength, 8pF I/O Capacitance – Series 1 – A2450PG
Get a grip on switching your industrial loads with this solid-state relay from Sensata | Crydom. It opens and closes your circuits to give you reliable, automated control of your equipment. As it has no mechanical parts, this unit is immune to wear, so you can depend on it for long-term performance. This powerhouse has a high dielectric strength of 4000Vrms, meaning it handles heavy-duty voltages without a hitch. You’ll find an SSR like this one used in the automotive manufacturing industry.
Features & Benefits
• Integrated input status LED indicator for easy monitoring and troubleshooting
• Low I/O capacitance of 8pF to deliver high-integrity signals
• Screw and saddle clamp terminals make wired connections simple and secure
• Light weight of 86.5g to place minimal strain on your equipment
• Operating voltage range of 24 to 280V AC for compatibility with low-power systems
• Low I/O capacitance of 8pF to deliver high-integrity signals
• Screw and saddle clamp terminals make wired connections simple and secure
• Light weight of 86.5g to place minimal strain on your equipment
• Operating voltage range of 24 to 280V AC for compatibility with low-power systems
What’s the operating temperature range of this unit?
This piece of kit has a wide operating temperature range between -40°C and +80°C, making it a dependable choice for use in challenging conditions.
Approvals
UL Recognised; C-UL Recognised; VDE (Including Protection)
Zero Voltage Relays
Note
Temperature can affect current rating; please consult the data sheet for potential derating.
