Sensata Crydom Solid State Interface Relay, 32 V dc Control, 12 A rms Load, DIN Rail Mount | DR48D12
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 11 pcs
Mfr. Part No: DR48D12
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Sensata / Crydom |
| Maximum Control Voltage | 32 V dc |
| Maximum Load Current | 12 A rms |
| Mounting Type | DIN Rail |
| Maximum Load Voltage | 600 V rms |
| Minimum Control Voltage | 4 V dc |
| Control Voltage Range | 4 → 32 V dc |
| Switching Type | Zero Cross |
| Load Voltage Range | 48 → 600Vrms |
| Minimum Load Voltage | 48 V rms |
| Terminal Type | Screw |
| Depth | 18mm |
| Height | 90.3mm |
| Length | 83.7mm |
| Minimum Load Current | 0.15 A rms |
| Off State Leakage Current | 0.2mA rms |
| Maximum Turn On Time | 1/2 cycle |
| Dimensions | 83.7 x 18 x 90.3mm |
| Maximum Operating Temperature | +80°C |
| Minimum Operating Temperature | -30°C |
| Manufacturer Part No. | DR48D12 |
| Operating Temperature Range | -30 → +80°C |
Product Details
DIN Rail Mounting – SeriesOne DR SSRs
Zero voltage and random switching options available
Ratings of 3, 6 & 12 Amps
Load voltage ratings of 2 → 60 Vdc, 2 → 100 Vdc, 24 → 280 Vac and 48 → 600 Vac
Fits standard 35 mm DIN rail
LED input status indicator
AC or DC control voltages
100K-cycle UL 508 endurance rating for enhanced reliability
Ratings of 3, 6 & 12 Amps
Load voltage ratings of 2 → 60 Vdc, 2 → 100 Vdc, 24 → 280 Vac and 48 → 600 Vac
Fits standard 35 mm DIN rail
LED input status indicator
AC or DC control voltages
100K-cycle UL 508 endurance rating for enhanced reliability
Approvals
UL, cUL, CE
