Sensata Crydom Solid State Interface Relay, 32 V dc Control, 3 A Load, DIN Rail Mount | DR48D03
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 3 pcs
Mfr. Part No: DR48D03
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Sensata / Crydom |
| Maximum Control Voltage | 32 V dc |
| Maximum Load Current | 3 A |
| Mounting Type | DIN Rail |
| Maximum Load Voltage | 600 V ac |
| Minimum Control Voltage | 4 V dc |
| Control Voltage Range | 4 → 32 V dc |
| Switching Type | Zero Cross |
| Load Voltage Range | 48 → 600V ac |
| Minimum Load Voltage | 48 V ac |
| Terminal Type | Screw |
| Length | 87.6mm |
| Height | 83.7mm |
| Minimum Load Current | 150 mA |
| Depth | 11mm |
| Dimensions | 87.6 x 11 x 83.7mm |
| Maximum Turn On Time | 1/2 cycle |
| Off State Leakage Current | 0.1 mA |
| Operating Temperature Range | -30 → +80°C |
| Manufacturer Part No. | DR48D03 |
Product Details
DIN Rail Mounting – SeriesOne DR SSRs
Zero voltage and random switching options available
Ratings of 3, 6 & 12 Amps
Load voltage ratings of 2 → 60 Vdc, 2 → 100 Vdc, 24 → 280 Vac and 48 → 600 Vac
Fits standard 35 mm DIN rail
LED input status indicator
AC or DC control voltages
100K-cycle UL 508 endurance rating for enhanced reliability
Ratings of 3, 6 & 12 Amps
Load voltage ratings of 2 → 60 Vdc, 2 → 100 Vdc, 24 → 280 Vac and 48 → 600 Vac
Fits standard 35 mm DIN rail
LED input status indicator
AC or DC control voltages
100K-cycle UL 508 endurance rating for enhanced reliability
Approvals
UL, cUL, CE
