Sferaco Polypropylene Hydraulic Quick Connect Coupling Female 1 in | 2211006

Name: Sferaco Polypropylene Hydraulic Quick Connect Coupling Female 1 in | 2211006
SKU: 936-936
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 8 pcs

Mfr. Part No: 2211006

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 936-936 Categories: Hydraulic Quick Connect Couplings, Sferaco

Description

Specifications

Attribute	Value
Brand	Sferaco
Product Type	Hydraulic Quick Connect Coupling
Thread Size	1 in
Material	Polypropylene
Series	2211
Sub Type	Cam Lock Coupling
Thread Standard	ISO 7-1 R ISO 7-1 Rp
Minimum Operating Temperature	0°C
Thread Gender	Female
Standards/Approvals	ISO 9001:2015 Directive 2014/68/EU:Products excluded from Directive (Article 4,3) MIL-C-27487 and A-A 59326 ISO 7-1 Rp ISO 7-1 R
Maximum Operating Pressure	6 bar
Maximum Operating Temperature	70°C

Product Details

The Sferaco Polypropylene cam lock couplers are designed for all common fluids of the second group with female male BSP and hose coupling connections. They operate within a temperature range of 0°C to +70°C and are manufactured under ISO 9001 2015 certification. These couplers are excluded from directive 2014/68/EU as stated in article 4 section 3 and are designed according to MIL C 27487 and A A 59326 standards. The threaded female BSP is cylindrical according to ISO 7-1 Rp while the male BSP is conical according to ISO 7-1 R.

Polypropylene fittings

EPDM gasket with the couplers

Stainless steel cam
