SICK Background Suppression Photoelectric Sensor, Block Sensor, 150 mm → 500 mm Detection Range | WTB250-2R1641
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 16 pcs
Mfr. Part No: WTB250-2R1641
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | SICK |
| Sensor Style | Block |
| Detection Type | Background Suppression |
| Detection Range | 150 mm → 500 mm |
| Output Type | Relay |
| Electrical Connection | 5 Wire Cable 5 m |
| Maximum AC Voltage | 240V |
| Maximum DC Voltage | 240V |
| Light Source | LED |
| IP Rating | IP67 |
| Response Time | <15 ms |
| Series | W250-2 |
| Maximum Operating Temperature | +55°C |
| Minimum Operating Temperature | -25°C |
| Housing Material | ABS |
| Mounting Type | Panel Mount |
| Standards Met | CE, cULus, EN 60947-1, EN 60947-5-2 |
Product Details
Photoelectric W250 Sensors
SICK W250-2 series photoelectric sensors have long adjustable sensing distances. Designed for use in a wide variety of applications that reach far beyond handling, packaging, warehousing and wood industries. A visible red light used for an alignment aid makes the W250 photoelectric sensors particularly user-friendly. Users are aided by an easy-to-read positioning indicator when adjusting sensitivity and sensing distance. LED indicators located on the top panel provide instant feedback of the detection status.
Features and Benefits
· Glass reinforced plastic housing rated to IP67 with status indicator
· Easily visible red LED light source for reliable detection
· Large adjustable sensing range
· LEDs on the sensor body for detection status
· Mounting bracket provided for simple mounting
· Easily accessible terminal chamber for electrical connections simplifies installation
· Overload, reverse polarity, and short circuit protected
· Light/Dark operating mode selectable via a control cable
· Configuration controls are protected by a cover, ensuring less damage
· Potentiometer with a positioning indicator for adjusting the sensing range/sensitivity
· Easily visible red LED light source for reliable detection
· Large adjustable sensing range
· LEDs on the sensor body for detection status
· Mounting bracket provided for simple mounting
· Easily accessible terminal chamber for electrical connections simplifies installation
· Overload, reverse polarity, and short circuit protected
· Light/Dark operating mode selectable via a control cable
· Configuration controls are protected by a cover, ensuring less damage
· Potentiometer with a positioning indicator for adjusting the sensing range/sensitivity
Supplied with
Mounting bracket
