SICK Colour Sensor LED 60 mm, Push Pull, 100 mA IO-Link, IP67 28.8 V | CSX-WNFA541282ZZZZZZZZZZZZ7ZZ1 / 1120190

Name: SICK Colour Sensor LED 60 mm, Push Pull, 100 mA IO-Link, IP67 28.8 V | CSX-WNFA541282ZZZZZZZZZZZZ7ZZ1 / 1120190
SKU: 392-544
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 15 pcs

Mfr. Part No: CSX-WNFA541282ZZZZZZZZZZZZ7ZZ1 / 1120190

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 392-544 Categories: Registration Sensors, SICK

Description

Specifications

Attribute	Value
Brand	SICK
Product Type	Colour Sensor
Light Source	LED
Output Type	Push Pull
Maximum Current	100mA
Switching Frequency	13.8kHz
Terminal Type	8-Pin M4 Male
Interface Type	IO-Link
LED Status Display	Yes
Series	1120190
Housing Material	Plastic, ABS
Maximum Supply Voltage	28.8V
Maximum Detection	60mm
IP Rating	IP67
Minimum Operating Temperature	-20°C
Maximum Operating Temperature	60°C
Standards/Approvals	IEC 60068-2-27
Mount Type	PCB

Product Details

Overview

The CSS/CSX High Speed color sensor is characterized by its high switching frequency and its precise, infinitely variable sensitivity adjustment. Furthermore, the sensor outputs color values (L*a*b or RGB) as well as the similarity of a detected color to a taught-in color. Thanks to its innovative teach-in procedure, the CSS/CSX High Speed also detects color gradients and structured materials. The switching outputs of the device can be binary coded in “Coded” mode without interfaces, which enables it to output up to 15 colors.

Up to 24 colors per identification task (job) can even be transferred via the IO-Link interface and saved externally. The sensor can be quickly and precisely configured for the specific application using the setup assistant in the SOPAS software.

At a glance

Switching frequency: 13.8 kHz

Output of color values (L*a*b or RGB) and color similarity

Output of up to 15 colors using the “Coded” mode

Up to 24 colors per identification task (job) can be saved

IO-Link interfaces; SOPAS software with application-specific setup assistant

CSX: installation-compatible to CS8

Your Benefit

Thanks to the fast object color detection, high process speeds can be achieved thereby increasing productivity

The output of up to 15 colors per binary coding of the switching outputs ensures easy data transmission – without interfaces such as IO-Link or Modbus®

Extends the process monitoring and diagnostics options through the output of color values and color similarity

Using IO-Link, up to 24 colors can be saved per identification task (job). This saves resources and increases the process flexibility

The sensor can be quickly configured correctly using the setup assistant in the SOPAS software. This makes commissioning easier and increases the process stability.

Applications

Mark and object positioning: detecting colored marks, labels, adhesive areas (splicing)

Fast sorting of objects by color: e.g., components in the automotive industry and machine construction; containers and pallets in intralogistics; vial and beverage bottle lids

Electronics:

Spliceband detection
