Sick Distance Distance Sensor, Rectangular Sensor IO-LINK | UC12-1123E
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 6 pcs
Mfr. Part No: UC12-1123E
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | SICK |
| Sensor Style | Rectangular |
| Detection Type | Distance |
| Output Type | PNP/NPN |
| Electrical Connection | M12 Connector |
| Maximum DC Voltage | 30V |
| Communication Protocol | IO-LINK |
| Terminal Type | M12 Connector |
| IP Rating | IP65, IP67 |
| Maximum Current | 500 mA |
| Interface | IO-Link |
| Response Time | 30 ms |
| Minimum Operating Temperature | -25°C |
| Housing Material | Metal, Zinc Diecast |
| Series | UC12 |
| Maximum Operating Temperature | +70°C |
| Thread Size | M12 |
| Standards Met | CE |
Product Details
Overview
The UC12 Ultrasonic sensors product family in the proven cubic metal housing is very rugged and at the same time easy to handle. Thanks to complementary digital outputs with IO-Link, it combines high flexibility with the well-known reliability of ultrason
–
At a glance
Rugged and proven housing design
Fast teach-in of the complementary digital outputs via pushbutton or IO-Link
Optimal background suppression
Integrated temperature compensation
Detection, measurement, or positioning with ultrasound
Regardless of material
Fast teach-in of the complementary digital outputs via pushbutton or IO-Link
Optimal background suppression
Integrated temperature compensation
Detection, measurement, or positioning with ultrasound
Regardless of material
Your Benefit
Proven cubic housing shape provides compatibility to other technologies
High flexibility due to IO-Link enables dynamic adaptation to changing application requirements
The complementary digital outputs signal cable breakage to prevent production errors
In
High flexibility due to IO-Link enables dynamic adaptation to changing application requirements
The complementary digital outputs signal cable breakage to prevent production errors
In
Applications
Detection, measurement or positioning of shiny and transparent materials
Level control for liquids and bulk materials
Diameter check for metal, paper, and plastic coils
Continuous detection of fabrics and wire grids
Detection of dark wooden boards and shi
Level control for liquids and bulk materials
Diameter check for metal, paper, and plastic coils
Continuous detection of fabrics and wire grids
Detection of dark wooden boards and shi
Note
Product details cover the whole product family. For details on the specifications for this individual product, please refer to the datasheet.
