SICK Laser Bar Code Reader | CLV632-6120 / 1041997

The CLV63x product family consists of compact, powerful fixed mount barcode scanners which were designed for a wide range of applications. The CLV63x combines a high reading performance with the improved SMART code reconstruction system: A reading algorithm that can accurately detect barcodes even if they are damaged or partially covered. Integrated function buttons and a built-in LED bar graph enable the device to be commissioned quickly, the reading diagnosis to be started easily, and a matchcode to be taught in without a PC.

The parameterization of the scanner can be saved externally via a microSD memory card.A variety of reading distances can be covered by long-, mid- and short-range variants. All variants such as line or grid scanners, side light emission and oscillating mirrors as well as Ethernet versions are available.

Integrated function buttons, e. g., for starting auto setup or reading quality evaluation

Integrated LED bar graph

CAN, Ethernet TCP/IP, PROFINET, and EtherNet/IP on board. No additional Ethernet gateway required (for “Ethernet” connection type)

Enhanced SMART code reconstruction technology

Flexible sorting, filtering, and logical functions

Advanced, easy-to-use SOPAS configuration software

High scanning frequency of up to 1,200 Hz

Advanced remote diagnostics and network monitoring capabilities available over Ethernet

Intelligent auto setup and multi-function pushbuttons save time during commissioning

Easily execute firmware updates using the microSD memory card: no need for a PC

Enhanced SMART technology reads damaged and partially obscured codes, increasing read rates

Increased scanner intelligence enables sophisticated configuration of logical operations, reducing the control system programming effort. Data is then delivered in the desired format

Real-time code identification even at very high conveyor speeds

Increased scanning reliability due to high-performance computing power and high scanning frequency

Fields of applications

Warehouse conveyor technology: picking station, identification of secondary packaging, pallet foot identification

Consumer goods industry: serialization and package content monitoring

Aggregation of food and pharmaceutical packaging
