SICK MLG Series | MLG05S-0145A10501

With the MLG-2 measuring automation light grid, SICK is offering the right solution for a wide range of applications in logistics and factory automation. The MLG-2 Prime, MLG-2 Pro and MLG-2 ProNet device variants are used in challenging applications with transparent objects and high object speeds, to name a couple of examples. With a resolution of up to 1.25 mm, the new “cross beam measurement” function and the “transparent” mode, the MLG-2 masters measuring task with high precision.

The pre installed solutions in the SOPAS ET configuration software allow even complex applications, such as object width measurement, to be parameterized with ease. The MLG-2 Pro and MLG-2 ProNet feature common industrial interfaces such as the RS845 or Ethernet interfaces.

Beam separation: 2.5 mm, 5 mm, 10 mm, 20 mm, 25 mm, 30 mm, 50 mm

Maximum range: 12 m

Functions: Cross beam measurement, 4 x zone measurement, high-speed scan, transparent mode

Interfaces: PNP, analogue, RS485, IO-Link, PROFINET, PROFIBUS, EtherCAT®, EtherNet/IPTM, CANopen

Sun resistance mode with reliable switching threshold

High measurement accuracy for detecting even very small objects reliably

Transparent mode function for reliably detecting and measuring transparent objects

The high-speed scan offers short response times for safely detecting objects traveling at high speeds

The SOPAS ET configuration software with menu-driven wizard for quick configuration

Ambient light immunity enables greater reliability

Integrated interfaces and matching function blocks reduce the time and effort involved in the commissioning process

Simple maintenance without the need for specialist staff thanks to the cloning function with IO-Link

Fields of applications

Packaging industry: Robot control and 3D measurement

Logistics: Volume measurement

Logistics: Package orientation

Logistics: Height and overhand measurement in dynamic storage systems

Machine tools: Measurement of work pieces and to
