Specifications
| Attribute | Value |
|---|---|
| Brand | SICK |
| Sensor Style | Block |
| Detection Type | Retroreflective |
| Detection Range | 3 m |
| Output Type | PNP |
| Electrical Connection | M8 Connector |
| Maximum DC Voltage | 30V |
| Terminal Type | 4 Pin Connector |
| Light Source | LED |
| IP Rating | IP67 |
| Response Time | 500 μs |
| Minimum Operating Temperature | -25°C |
| Series | W8G |
| Housing Material | Plastic |
| Maximum Operating Temperature | +55°C |
Product Details
Overview
At a glance
Standard miniature housing with M3 threaded mounting holes
Light/dark switching selectable via rotary switch
Adjustable sensing range
Necessary accessories are included with delivery
Your Benefit
Highly visible light spot makes alignment quick and easy
Reliable detection of all materials, including small and/or transparent objects, min. attenuation 15 %
All necessary accessories (bracket and reflector) are included with delivery, reducing installation and procurement costs
M3 mounting hole provides quick installation
