Specifications
| Attribute | Value |
|---|---|
| Brand | SICK |
| Sensor Style | Rectangular |
| Detection Type | Retroreflective |
| Detection Range | 6 m |
| Output Type | PNP |
| Electrical Connection | Cable |
| Switching Mode | Light / Dark switching |
| Maximum DC Voltage | 30V |
| Terminal Type | Cable with Connector |
| Light Source | PinPoint LED |
| IP Rating | IP67 |
| Maximum Current | 100 mA |
| Response Time | 625 μs |
| Housing Material | ABS/PC, Plastic |
| Series | G6 |
| Maximum Operating Temperature | +55°C |
| Mounting Type | Threaded |
| Minimum Operating Temperature | -25°C |
| Standards Met | CE, cULus |
Product Details
Overview
At a glance
SICK ASIC, the result of decades of experience with photoelectric sensors
Photoelectric proximity sensors with background suppression, energetic photoelectric proximity sensors, and through-beam photoelectric sensors
ABS plastic housing and V4A stainless-steel 1.4404 (316L) housing
Enclosure ratings IP67 and IP69K
Your Benefit
and are therefore suitable for a broad range of applications
Superior optical performance and robustness thanks to the ASIC from SICK
Quick and easy mounting and high durability thanks to the metal inserts with M3 thread
Easy installation and adjustment with user friendly potentiometer and highly visible indicator LEDs
Variants with a stainless steel housing and IP69K enclosure rating ensure a long sensor service life in demanding wash-down applications
Applications
Harsh environments requiring tough metal housing. e.g. due to mechanical impacts
Applications with high aesthetic standards
