Specifications
| Attribute | Value |
|---|---|
| Brand | SICK |
| Sensor Style | Rectangular |
| Detection Type | Retroreflective |
| Detection Range | 7.2 m |
| Output Type | PNP |
| Switching Mode | Light / Dark switching |
| Electrical Connection | Cable |
| Maximum DC Voltage | 30V |
| Terminal Type | M8 3 Pin Connector |
| Light Source | LED |
| IP Rating | IP67 |
| Maximum Current | 100 mA |
| Response Time | 0.5 ms |
| Housing Material | ABS, Plastic |
| Minimum Operating Temperature | -25°C |
| Mounting Type | Threaded |
| Maximum Operating Temperature | +55°C |
| Series | WL100 |
| Standards Met | CE, UL |
Product Details
Overview
At a glance
WT100-2 photoelectric proximity sensor (energetic or with background blanking)
WL100-2 photoelectric retro-reflective sensor
WS/WE100-2 through-beam photoelectric sensor
Various connection types available (standard: 2 m cable
Light/dark switching and sensitivity adjustment possible
Wide range of accessories
Your Benefit
Short downtime and high throughput thanks to reliable object detection
Ability to handle a wide range of detection principles within a single standardized housing, reducing the number of model variants
Simple commissioning thanks to easily visible display LEDs
Easy to set up thanks to user-friendly potentiometer (dependent on model)
Standard housing that is compatible with many commonly used mounting systems
Easy mounting thanks to 1-inch hole spacing
High level of operating reserve minimizes susceptibility to contamination
Applications
Storage and conveyor systems in the logistics industry
Detection of a wide variety of objects in packaging processes
Reliable detection of people in door and gate applications
