SICK SIG350 Series Sensor Box, M12 | SIG350-0005AP100

The SIG350 Sensor Integration Gateway is an IO-Link master that bundles and controls sensor communication via 8 IO-Link ports. The SIG350 allows for seamless integration and loss-free data transmission from the sensor to the cloud – and with reduced cabli

The PROFINET, EtherNet/IP and EtherCAT industrial protocols are available for network communication. Thanks to IO-Link even during operation, an integrated web server allows for intuitive configuration of the IO-Link master as well as the connected sensor

8 IO-Link ports (M12

5-pin

A-coded

Class A/B)
Current carrying capacity of up to 16 A at max. 4 A per port for US and UA
Rugged IP67 housing
Operating temperature –30 °C … +70 °C
PROFINET, EtherNet/IP and EtherCAT available
REST API, MQTT and OPC UA

Enables loss-free communication between a large number of sensors or actuators and the higher-level plant controller
Simple and transparent data integration thanks to uniform wiring concept with IO-Link
Innovative IO-Link ports that can be freely configur

Integration of IO-Link devices and digital switching signals in all areas of factory, logistics, and process automation
Areas where sensors or actuators require class B ports
Direct integration of IO-Link sensor and actuator data in IIoT landscapes

Product details cover the whole product family. For details on the specifications for this individual product, please refer to the datasheet.
